Drive Axle for Forklifts

Forklift Drive Axle - A forklift drive axle is actually a piece of equipment which is elastically connected to a vehicle frame utilizing a lift mast. The lift mast is attached to the drive axle and can be inclined round the axial centerline of the drive axle. This is done by no less than one tilting cylinder. Frontward bearing parts together with back bearing parts of a torque bearing system are responsible for fastening the drive axle to the vehicle frame. The drive axle could be pivoted around a swiveling axis oriented transversely and horizontally in the vicinity of the rear bearing elements. The lift mast can also be inclined relative to the drive axle. The tilting cylinder is affixed to the lift truck frame and the lift mast in an articulated fashion. This enables the tilting cylinder to be oriented nearly parallel to a plane extending from the axial centerline and to the swiveling axis.

Unit H35, H40, and H45 forklifts, that are made by Linde AG in Aschaffenburg, Germany, have a mounted lift mast tilt on the vehicle framework itself. The drive axle is elastically attached to the frame of the lift truck by numerous various bearings. The drive axle contains a tubular axle body together with extension arms attached to it and extend rearwards. This particular type of drive axle is elastically affixed to the vehicle framework using back bearing elements on the extension arms together with frontward bearing devices located on the axle body. There are two back and two front bearing tools. Each one is separated in the transverse direction of the lift truck from the other bearing device in its respective pair.

The drive and braking torques of the drive axle are maintained through the back bearing components on the frame by the extension arms. The load and the lift mast generate the forces which are transmitted into the street or floor by the frame of the vehicle through the drive axle's front bearing elements. It is essential to make certain the elements of the drive axle are constructed in a rigid enough manner to maintain strength of the lift truck truck. The bearing parts could minimize minor bumps or road surface irregularities through travel to a limited extent and give a bit smoother operation.
