Forklift Pinions

Forklift Pinion - The king pin, normally made out of metal, is the major axis in the steering device of a motor vehicle. The initial design was actually a steel pin wherein the movable steerable wheel was attached to the suspension. Able to freely revolve on a single axis, it limited the levels of freedom of movement of the rest of the front suspension. During the nineteen fifties, when its bearings were substituted by ball joints, more comprehensive suspension designs became accessible to designers. King pin suspensions are nevertheless featured on several heavy trucks as they have the advantage of being capable of carrying a lot heavier load.

The new designs of the king pin no longer restrict to moving like a pin. Now, the term may not even refer to an actual pin but the axis in which the steered wheels turn.

The KPI or kingpin inclination could likewise be called the steering axis inclination or SAI. These terms describe the kingpin if it is set at an angle relative to the true vertical line as looked at from the back or front of the forklift. This has a major effect on the steering, making it likely to go back to the centre or straight ahead position. The centre arrangement is where the wheel is at its highest position relative to the suspended body of the lift truck. The vehicles' weight has the tendency to turn the king pin to this position.

Another effect of the kingpin inclination is to fix the scrub radius of the steered wheel. The scrub radius is the offset among the tire's contact point with the road surface and the projected axis of the steering down through the king pin. If these points coincide, the scrub radius is defined as zero. Though a zero scrub radius is possible without an inclined king pin, it needs a deeply dished wheel in order to maintain that the king pin is at the centerline of the wheel. It is more practical to tilt the king pin and use a less dished wheel. This likewise offers the self-centering effect.
