Chains for Forklift

Forklift Chain - The life of the lift truck lift chains can be lengthened with correct maintenance and care. Lubricating correctly is actually an excellent way in order to lengthen the capability of this particular forklift component. It is vital to apply oil every so often making use of a brush or whatever lube application device. The frequency and volume of oil application needs to be adequate to be able to stop any rust discoloration of oil in the joints. This reddish brown discoloration generally signals that the lift chains have not been properly lubricated. If this particular situation has occurred, it is really essential to lubricate the lift chains right away.

All through lift chain operation it is normal for some metal to metal contact to happen that could cause some parts to wear out in the long run. Once there is three percent elongation on the lift chain, it is considered by industry standards to have worn out the chain. To be able to stop the scary chance of a catastrophic lift chain failure from happening, the maker very much recommends that the lift chain be replaced before it reaches three percent elongation. The lift chain lengthens due to progressive joint wear which elongates the chain pitch. This elongation could be measured by placing a certain number of pitches under tension.

In order to ensure good lift chain maintenance, another factor to consider is to check the clevis pins on the lift chain for indications of wearing. Lift chains are assembled so that the clevis pins have their tapered faces lined up with each other. Usually, rotation of the clevis pins is frequently caused by shock loading. Shock loading occurs when the chain is loose and then suddenly a load is applied. This causes the chain to experience a shock as it 'snaps' under the load tension. Without the correct lubrication, in this particular situation, the pins can rotate in the chain's link. If this scenario happens, the lift chains must be replaced right away. It is essential to always replace the lift chains in pairs so as to ensure even wear.
